SECTION 1 - SPECIFICATIONS
1-2
– JLG Sizzor –
3120829
NOTE: Wheel lugs should be torqued to 109 Nm (80 ft lb) at
50 hour intervals.
When maintenance becomes necessary or a fas-
tener has loosened, refer to Figure 1-3., Torque
Chart, to determine proper torque value.
Hydraulic Filter - Inline
Return - Bypass Type
25 Micron Nominal
1.3
PERFORMANCE DATA
Travel Speed
2 Wheel Drive - 5.6 kmh (3.5 mph)
4 Wheel Drive - 4.5 kmh (2.8 mph)
Gradeability
2 Wheel Drive - 25% (14°)
4 Wheel Drive - 45% (24°)
Turning Radius (Outside)
2 Wheel Steer - 4.0 m (13 ft 2 in)
4 Wheel Steer - 2.0 m (6 ft 6 in)
Lift Speed - 400RTS
Up - 42 - 50 seconds
Down - 60 - 70 seconds
Lift Speed - 500RTS
Up - 65 - 80 seconds
Down - 70 - 80 seconds
Platform Capacity - Fixed Platform
400RTS - 905 kg (2,000 lb)
500RTS - 1135 kg (2,500 lb)
Platform Capacity - Traversing Platform
Extension (If Equipped)
400RTS (With Deck Extended)
Machine Capacity - 680 kg (1,500 lb)
Extension - 265 kg (500 lb)
500RTS (With Deck Extended)
Machine Capacity - 905 kg (2000 lb)
Extension - 265 kg (500 lb)
With Deck Retracted
400RTS - 680 kg (1,500 lb)
500RTS - 900 kg (2,000 lb)
Platform Capacity - Dual Extensions
400RTS - 680 kg (1,500 lb)
500RTS - 900 kg (1,984 lb)
Platform Capacity - Wide Deck, Dual
Extensions (500RTS Only)
500RTS - 680 kg (1,500 lb)
Machine Weight
400RTS - Approx. 6,797kg (14,985 lb)
500RTS - Approx. 6,940 kg (15,300 lb)
Machine Height (Platform Lowered)
400RTS - 2.9 m (116 in)
500RTS - 3.15 m (126 in)
Machine Length
4.72 m (15 ft 5 in)
Machine Width
Standard Tires - 2.3 m (7 ft 6 in)
Foam Filled Tires - 2.3 m (7 ft 7 in)
1.4
LUBRICATION
NOTE: Hydraulic oils must have anti-wear qualities at least
to API Service Classification GL-3, and sufficien-
themical stability for mobile hydraulic system ser-
vice. JLG Industries recommends Mobil 424
hydraulic oil, which has an SAE viscosity of 10W-20
and viscosity index of 152.
Table 1-1. Hydraulic Oil
HYDRAULIC SYSTEM OPERATING
TEMPERATURE RANGE
SAE VISCOSITY GRADE
0 to +23 degrees F
(-18 to -5 degrees C)
10W
0 to +210 degrees F
(-18 to +100 degrees C)
10W-20,10W-30
+50 to +210 degrees F
(+10 to +100 degrees C)
20W-20
