21
Choose a good, cleared assembly
area and get a friend to help you put
your grill together. Lay cardboard
down to protect grill finish and
assembly area.
CAUTION! Some parts may
contain sharp edges.
Wear protective gloves
if necessary.
Step 1
Remove the two bolts from the top
corner of the back panel. With the
help of a friend, lift the back panel
out and take it to a clear area.
Remove all the parts boxes from
the base.
Note: Keep these two bolts,
do not throw them away.
They will be used in Step 3.
Step 2
Add six M6 x 12mm bolts to the
middle grill base bracket as
illustrated and tighten securely.
Back Panel Bolts
