4
1. To mount the exchangeable Thermoblock for slides DC, open the lid by
simultaneously pressing the two pressure points on the front edge of the lid.
The pressure points are labeled with "push".
2. Alternately unscrew the 2 screws of the pressure plate until the pressure is
completely released (Figure 1).
3. Adjust the exchangeable Thermoblock for slides DC on the basic device in
such a way that the label can be seen from the front. Screw it tight using a
Hexagon key.
Figure 1: Drawing of the
Thermoblock for slides DC
1 Pressure plate
2 Screws
3 Lid seal
4 Label
4
2
1
3
3 Mounting
