Eppendorf Thermoblock slides - Manual (Page 6)

15
In order to effectively counteract evaporation of reaction solution from the
reaction area, a "damp chamber" can also be applied during temperature control
and rotation. For this purpose three recesses between the slide positions have
been provided on the exchangeable Thermoblock, in which related polymer
strips serve as moisteners following a brief dampening with desalted water.
The Silverquant ® adapter is held by four rods on the lid (fig. 3).
1
2
3
Slide positions
Recess for reservoir pads
Fig. 1: Exchangeable
Lid seal and fixing
for the slides projections
1
2
3
Thermoblock slides
4 Application
