Page 7: Component identification -1
Chapter 2. Specifications
■ Component Identification
S2545 – 0410002
page 2 - 1
45 in
114.3 cm
44 in
111.8 cm
Operator’s
Manual Holder
78.5 in - 199.4 cm
Rails Lowered
89 in - 226.1 cm
Rails Raised or
Fixed Rails
90 in
228.6 cm
78 in
198.1 cm
95 in
241.3 cm
4 in - 10.2 cm Platform Lowered
1.25 in - 3.2 cm Platform Raised
Guardrails
Platform Extension
Upper Controls
Platform
Scissors
Structure
Chassis
Toeboards
36 in
91.4 cm
Front (Steer)
Hydraulic Tray (Right Side)
Battery Tray (Left Side)
Pothole
Protector Skid
Lower Controls
Rear
