Chapter 2 – Specifications
SB47JRT – 0075522
5
General Specifications
Aerial Platform
Working height
16 m (52
′
6
″
)
Maximum platform height
14.2 m (46
′
6
″
)
Horizontal reach
11.9 m (39
′
)
Main boom
Articulation
-18° to +75°
Extension
2.5 m (8
′
4.75
″
)
Turntable rotation
360° continuous
Turning radius, inside
Two wheel drive
1.6 m (5
′
2
″
)
Four wheel drive
1.7 m (5
′
6
″
)
Wheelbase
2.4 m (8
′
)
Ground clearance
25 cm (10
″
)
Maximum wheel load
2,495 kg (5,500 lbs)
Maximum ground pressure
3.8 kg/cm² (54 psi)
Weight, GVW
Approximate
6,123 kg (13,500 lbs)
Stowed width
2.4 m (7
′
11.5
″
)
With flotation tires
2.6 m (8
′
7.5
″
)
Stowed length
8.1 m (26
′
9
″
)
Stowed length, tucked stow
6.5 m (21
′
3.5
″
)
Stowed height
2.3 m (7
′
9
″
)
Stowed height, tucked stow
2.4 m (7
′
11.5
″
)
Platform
Dimensions
Standard steel
76 cm x 152 cm (30
″
x 60
″
)
Rated work load
227 kg (500 lb)
Optional aluminum
76 cm x 234 cm (30
″
x 92
″
)
Rated work load
227 kg (500 lb)
Optional aluminum
76 cm x 152 cm (30
″
x 60
″
)
Rated work load
227 kg (600 lb)
Rotation
90° CW to 80° CCW
Maximum number of occupants
2 people
Optional AC generator
220 VAC
Function Speed
Turntable rotation, 360 degrees
108 to 113 seconds
Main boom
Up
65 to 70 seconds
Down
65 to 70 seconds
Extend
40 to 45 seconds
Retract
25 to 30 seconds
Jib
Up
25 to 35 seconds
Down
25 to 35 seconds
Platform rotation, 170 degrees
8 to 15 seconds
Drive
High, booms stowed
4.8 km/h (3.0 mph)
Low, booms elevated
1.6 km/h (1.0 mph)
Drive System
Standard
Four wheel drive
Optional
Two wheel drive
Gradeability
25%
Tires
Street tread, 10 ply
30 cm x 42 cm (12
″
x 16.5
″
)
Bar lug, 10 ply
30 cm x 42 cm (12
″
x 16.5
″
)
Flotation, 10 ply
33/16LL-16.1
Foam filled, 10 ply
Street tread or bar lug
Electrical System
Voltage
12 V DC negative chassis ground
Source
Two - 12 V 600 CCA batteries
Fluid recommended
distilled water
Hydraulic System
Maximum pressure
19,305 kPa (2,800 psi)
Reservoir capacity
62.4 l (16.5 US gal)
System capacity
94.6 l (25 US gal)
Maximum operating temperature
93°C (200°F)
Hydraulic fluid recommended
Above -13°C (10°F)
Mobil DTE-13M
(ISO VG32)
Below -13°C (10°F)
Mobil DTE-11M
(ISO VG15)
Engine
Diesel
Cummins B3.3
Diesel
Deutz F3L-2011F
Fuel Tank Capacity
Diesel
75.7 l (20 US gal)
Ambient Air Temperature Operating Range
Celsius
-18°C to 43°C
Fahrenheit
0°F to 110°F
Maximum Wind Speed
Gust or steady
45 km/h (28 mph)
