Page 6 of 25 Pop-Up PUSH 8 ECO Operator’s Safety and Maintenance Handbook ( rev.0.0.1.0210)
Section 2
SPECIFICATION
Technical data
Safe working load (SWL) 240kg
equivalent to 1 person + 160kg tools and materials
Maximum platform height 2.5 metres
Maximum working height 4.5 metres
Platform length 1.01 metres
Platform width 0.52 metres
Platform guard rail height 1.10 metres
Toe board height 0.15 metres
Maximum allowable manual force 200 Newtons
Maximum allowable wind speed 0 metres/sec*
Maximum allowable chassis inclination 0 degrees
Electrical system 12 volt DC
Motor 0.7 kW
Batteries 1 x 80 Ah
Battery charger Universal 90V to 240V AC
Hydraulic system
Maximum pressure
13 MPa
Reservoir capacity 1.22 litre
Function speeds (approx.)
Raise
24 seconds
Lower 25 seconds
Approx. no. of lifts (fully charged with SWL) 120
Overall length 1.26 metres
Overall height (stowed) 1.72 metres
Overall width (with stabilisers deployed) 1.30 metres
Overall width (without stabilisers) 0.70 metres
Overall mass (GVW) without stabilisers 343kg
Overall mass (GVW) with stabilisers 365kg
Weight (without stabilisers) 343kg
Maximum wheel load 350kg
*For use in indoor exposed areas up to 12.5m/sec wind speed – pack available on request
