Operation
MB20NMB26
3.2
The pre-operation safety checks should be carried
out prior to operation. These checks are detailed in
the previous section. Operators who follow these
guidelines will become familiar with the controls and
indicators on the machine.
This section summarises the controls and indicators
in tabular form and provides more detailed
information.
Upper Control Box & Console
Controls and Indicators
1
3
2
4
5
6
10
9
7
8
1
DO NOT operate the machine from the upper controls
until the platform entrance drop-bar is in the fully
lowered position and your safety harness has been
fitted and attached.
WARNING WARNING WARNING WARNING WARNING
Page 9
