Snorkel M2032J - Manual (Page 80)

Decals
BATTERIES
057429-000
501455-000
501643-000
058186-000
501573-000
508503-000
USE BATTERY FILL
SYSTEM AFTER
BATTERIES HAVE BEEN
CHARGED.
FILLING BEFORE
CHARGING
COULD CAUSE
OVERFLOW.
569295
WARNING !
CRUSHING HAZARD
KEEP CLEAR OF
BOOM MECHANISM
LOWER PLATFORM
COMPLETLY BEFORE
SERVICING MACHINE.
MEETS OR EXEEDS
THE REQUIREMENTS OF
ANSI A92.5 1999
manufacturer
TIP-OVER HAZARD
BATTERIES ACT AS COUNTERWEIGHT
EACH REPALCMENT BATTERY SHALL WEIGH
60LBS. OR MORE
WARNING !
058537-000
PINCH POINT
KEEP ALL BODY
PARTS AWAY
HYDRAULIC FLUID
HYDRULIKOEL
HUILE HYDRAULIQUE
FLUIDO HIDRAULICO
WARNING !
Explosive gas is
generated when charging
batteries
DO NOT expose to sparks
or flames.
066552-000
066552-000
The fitment of any component other that approved
items designed for use with this machine can result
in serious danger to operators, property and bystanders.
DO NOT fit replacment parts other than genuine
components without the express written approval from
the manufacturer.
All personnel shall be qualified, carefully read, understand and obay all safety rules,operating instructions
and manual of responsibilities before performing maintenance on or operating any mobile elevating work
platform.
1. Do not use a damaged or malfunctioning machine.
2. Be sure all labels, operating instructions & instruction manuals are in place and legible.
3. If alarm sounds when boom is stowed do not operate boom functions. Move to a firm level surface.
4. If alarm sounds when elevating STOP, turn key to "Emergency Down", then carefully lower platform. DO
NOT rotate booms before significantly reducing the outreach.
5. In case of emergency push emergency stop button. 058539-002
DO NOT exceed maximum platform capacity
Of 475 pounds (215kg) or 2 occupants.
DO NOT exceed 90 pounds (400N) side force.
DO NOT raise or extend boom unless machine
Is on firm level surface.
DO NOT drive into holes or over drop -offs
while elivated .
DO NOT use when wind exceeds force 6
(27 MPH, 12.5 m/s)
All platform occupants shall wear an
approved fall restraint properly attached to
designate anchorage points.
DO NOT stand, sit or climb on platform rails.
Ensure gate midrail is fully lowered before
operating.
DO NOT climb down booms.
DO NOT use ladders or scaffolding on
platform.
THIS MACHINE IS NOT INSULATED.
DO NOT operate within 10 feet ( 3m) of power
lines or electrical apparatus.
Look up, down and around for electrical wires.
Check work area for overhead obstructions or
other possible hazards.
Thoroughly check all clearances before
positioning platform. 058538-000
Failure to read, understand and obey the following safety rules will cause
DEATH or SERIOUS INJURY.
M2032J
OFF
ON
2
1
3
4
5
6
7
26
27
27
8
9
10 11
20
13
14
15
16
17
18
19
12
M2639J
23
OPERATORS CHECKLIST
INSPECT AND/OR TEST THE FOLLOWING DAILY
OR AT THE BEGINING OF EACH SHIFT
1. UWHLE FUWEHLI QUFH LEULIEO WEUBF
2. JDHW LUIOHLWNC EIOFLEI
3. SISJDL UEH IOWEJP IOIP IIOP
4. NJI IOP [DIFJWPEIOFJDN KJ IJUNHFL
5. OIHJOPWO JK OIJPOI OJI
6. H HUOI JKHILHB IJPIJ BN
7. HJBUIHO IOJ IJIOJIOIJ
8. UYIOBUHIOU YT YUGHIU IOJ PJJ OJ
9. JNK MNMNBV,N NMBJ NLJNL JKN JLKM;KM;
10. UGVUVUV GUY YGUYY BNDFSES
11. HJGVJ JHB H BPL KLIO PO OPP OPO
24
25
21
22
Safety Rules & Operating
Instructions Enclosed
MAXIMUM PLATFORM CAPACITY
475LBS. (2 OCCUPANTS)
All personnel shall be qualified, carfully read, undrestand
and obay all safety rules, operating instructions and
manual of reponsibilities before performing maintenance
on or operating any mobile elevating work platform.
508769-000
WARNING !
0665536-001
CRUSHING HAZARD
KEEP ALL BODY
PARTS AWAY
058531-000
068635-001
502480-000
501455-000
501643-000
058761-000
057429-000
058186-000
501573-000
058181-003
508503-000
057424-001
508336-000
058530-000
508333-000
058538-000
058533-000
058534-000
058537-000
060197-001
057434-000
058539-002
659295
300699
057425-001
508772-000
066556-001
