12 067449-001
3/00 D
Specifications*
FOR MORE INFORMATION
Local Distributor:
TEL: (800) 926-5438 or (559) 891-5200
FAX: (559) 896-9012
PARTS: (888) UR-PARTS
PARTSFAX: (559) 896-9244
1775 Park St., Selma, CA 93662
http://www.upright.com
Safety
Rules
and
Operating
Instructions
Safety
Rules
and
Operating
Instructions
* Specifications subject to change without notice.
Hot weather or heavy use may reduce performance.
Refer to Service Manual for complete parts and service information.
Meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999
LX41
143.38 in. x 70 in. [3.64 m x 1.78 m]
179.38 in. x 68 in. [4.56 m x 1.73 m]
156 in. x 68 in. [3.96 m x 1.73 m]
228 in. x 68 in. [5.79 m x 1.73 m]
1,500 lbs. [680 kg]
1,500 lbs. [680 kg]
500 lbs. [227 kg]
1250 lbs {567 kg]
500 lbs. [227 kg]
6 people
2 people
6 people
2 people
47 ft. [14.33 m]
40 ft. 6 in. [12.34 m]
65.3 in. [1.66 m]
2 WD : 11,260 lbs. [5,108 kg]
2 WD : 11,460 lbs. [5,194 kg]
2 WD : 11,690 lbs. [5,303 kg]
2
WD
: 11,890 lbs. [5,371 kg]
2 WD : 12,120 lbs. [5,498 kg]
2 WD : 12,318 lbs. [5,587 kg]
90 in. [2.29 m]
108.75 in. [2.76 m]
160.5 in. [4.08 m]
40 ft. 6 in. [12.34 m]
0 to 3.1 mph [0 to 5.0 km/h]
0 to 0.3 mph [0 to .48 km/h]
48 Volt DC
28.3 Gallons [107.13 l]
3000 psi [206.8 bar]
ISO #46
ISO #32
One Single Stage Lift Cylinder
Raise, 50 sec./Lower, 70 sec.
Eight 6V 350 AH Batteries
(BiEnergy) One Kubota 12 HP Diesel
Proportional
Smooth one hand Joystick
Two Electric Wheel Motors
10-16.5 NHS 8 Ply, 75psi [5.2 bar]
Poly Filled
Two, Spring Applied, Hydraulic Release,
Multiple Disc
48 in. [1.22 m]
2
WD : 30% [16.7º]
115.75 in. [2.94 m]
43.5 in. [1.1 m] high, Fold Down with Self
Closing Gate
6 in. [152 mm] High
LX31
143.38 in. x 70 in. [3.64 m x 1.78 m]
179.38 in. x 68 in. [4.56 m x 1.73 m]
156in. x 68 in. [3.96 m x 1.73 m]
228 in. x 68 in. [5.79 m x 1.73 m]
2000 lbs. [907 kg]
2000 lbs. [907 kg]
500 lbs. [227 kg] 1750
lbs [795 kg] 500
lbs. [227 kg]
8 people
2 people
8 people
2 people
37 ft. [11.28 m]
31 ft. [9.45 m]
56.3 in. [1.43 m]
2 WD : 9,920 lbs. [4,500 kg]
2 WD : 10,120 lbs. [4,590 kg]
2 WD : 10,350 lbs. [4,695 kg]
2
WD
: 10,550 lbs. [4,785 kg]
2 WD : 10,780 lbs. [4,890 kg]
2 WD : 10,980 lbs. [4,981 kg]
90 in. [2.29 m]
99.75 in. [2.53 m]
160.5 in. [4.08 m]
31 ft. [9.45 m]
0 to 3.1 mph [0 to 5.0 km/h]
0 to 0.3 mph [0 to .48 km/h]
48 Volt DC
28.3 Gallons [107.13 l]
3000 psi [206.8 bar]
ISO #46
ISO #32
One Single Stage Lift Cylinder
Raise, 40 sec./Lower, 60 sec.
Eight 6V 350 AH Batteries
(BiEnergy) One Kubota 12 HP Diesel
Proportional
Smooth one hand Joystick
Two Electric Wheel Motors
10-16.5 NHS 8 Ply, 75psi [5.2 bar]
Poly Filled
Two, Spring Applied, Hydraulic Release,
Multiple Disc
48 in. [1.22 m]
2
WD : 30% [16.7º]
115.75 in. [2.94 m]
43.5 in. [1.1 m] high, Fold Down with Self
Closing Gate
6 in. [152 mm] High
ITEM
Platform Size (Inside Toeboards)
Standard
w/ Extension
Double Deck Models
w/ Decks Retracted
w/ Decks Extended
Max. Platform Capacity
Standard
w/ Extension
on Extension
Double Deck Models
on Extension (one end only)
Max. No. of occupants
Standard
on Extension
Double Deck Models
on Extension (one end only)
Height
Working Height
Max. Platform Height
Min. Platform Height
Dimensions
Weight, Electric
BiEnergy
Electric w/ Extension
BiEnergy
Electric Double Deck
BiEnergy
Overall Width
Overall Height
Overall Length, Standard
Driveable Height
Surface Speed
Platform Lowered
Platform Raised
System Voltage
Hydraulic Tank Capacity
Maximum Hydraulic System Pressure
Hydraulic Fluid
Normal Use (>32 °F [0 °C])
Low Temp. Use
(-10 to 32 °F [-23 to 0 °C])
Lift System
Lift Speed
Power Source
Drive Control
Control System
Horizontal Drive
Tires
Standard
Optional
Parking Brakes
Turning Radius (inside)
Maximum Gradeability
Wheel Base
Guardrails
Toeboard
