Introduction
A62JRT – 104850-000 5
Introduction
This manual covers the A62JRT Aerial Work Platform.
This manual must be stored on the machine at all
times.
Read, Understand and follow all safety rules and op-
erating instructions before attempting to operate the
machine.
When contacting Snorkel for service or parts information,
be sure to include the MODEL and SERIAL NUMBERS
from the equipment nameplate. Should the nameplate
be missing, the SERIAL NUMBER is also stamped at
the rear of the chassis.
Component Identification
Right Side
Left Side
Lower
Controls
Platform
Hydraulic Fluid Tank
Battery
Steer Wheels
Platform
Foot Switch
Jib
Fuel Tank
Rear Front
Hydraulic Fluid Filter
Tie-Down/Lifting Lugs
Top Front of Chassis
Tie-Down/Lifting Lugs
Top Rear of Chassis
Lanyard
Anchors
Chassis
Upper Controls
Operator’s
Manual
Steer Wheels
Main Boom Tip Boom
Engine
Rear Front
Jib
Pivoting
Front Axle
Battery
Disconnect
Riser Boom
