Specifications
A62JRT – 104850-000 23
Specifications
Aerial Platform
Working height 20.6 m (67′ 8″)
Maximum platform height 18.8 m (61′ 8″)
Up and over height 9.0 m (29′ 6″)
Maximum horizontal reach 11.1 m (36′ 6.4″)
Main boom
Articulation 0° to +72.9°
Extension 3.1 m (10′1″)
Jib
Articulation -68.5° to +68.5°
Extension 1.82 m (6′)
Tail swing 0
Turntable rotation 360° non-continuous
Turning radius, outside 4.6 m (15′1″)
Turning radius, inside 1.4 m (4′ 7″)
Wheelbase 2.4 m (8′)
Ground clearance 350 mm (13.75″)
Weight, EVW approximate 10660 kg (23,500 lbs)
Width 2.4 m (8′)
Stowed length 8.6 m (28′ 2.5″)
Stowed height 2.56 m (8′ 5″)
Platform
Dimensions
Standard 1.0 m x 2.4 m (39″ x 96″)
Rated work load 227 kg (500 lb)
Rotation 180 degrees
Maximum number of occupants 2 people
Optional AC generator 110 V
Optional AC generator 220 V
Optional AC generator 220 V, 3-phase, 12 kw
Function Speed – Full Cycle
Turntable rotation
Booms retracted 100 seconds minimum
Riser
Up 43 seconds minimum
Down 43 seconds minimum
Main boom
Up 38 seconds minimum
Down 38 seconds minimum
Extend 30 seconds minimum
Retract 33 seconds minimum
Jib
Up 18 seconds minimum
Down 15 seconds minimum
Platform rotation 9 seconds minimum
Drive
High, booms stowed 6.1 km/h (3.8 mph)
Low, booms raised/extended 1.2 km/h (0.75 mph)
Drive System
Standard 4WD hydrostatic
Gradeability – theoretical 45%
Axle front oscillating
Vertical wheel travel 22.8 cm (9″)
Tires
Foam Filled Bar lug 355/55 D625, 14 ply
Electrical System
Voltage 12 V DC negative chassis ground
Source One - 12 V 660 CCA batteries
Fluid recommended distilled water
Hydraulic System
Pressure
Drive circuit maximum 41368 kPa (6,000 psi)
Boom circuit maximum 18960 kPa (2,750 psi)
Reservoir capacity 170 l (45 US gal)
Maximum operating temperature 93°C (200°F)
Hydraulic fluid recommended
Above 0°C (32°F) Mobil Fluid 424
Consistently between -17°C (0°F) and 0°C (32°F)
Mobil DTE-13M (ISO VG32)
Below -17°C (0°F) Mobil DTE-11M (ISO VG15)
Engine
Diesel Kubota V2403MT
Output 59hp/44kw
Fuel Tank Capacity
Diesel 174.1 l (46 US gal)
Ambient Air Temperature Operating Range
Fahrenheit 0°F to 110°F
Celsius -18°C to 43°C
Maximum Wind Speed
Gust or steady 45 km/h (28 mph)
Group Classification
Heavy Duty – intended life 100,000 load cycles
