Introduction
4 A46JRT – 0260228
Introduction
This manual covers the A46JRT Aerial Work Platform.
This manual must be stored on the machine at all
times.
Read, understand and follow all safety rules and operating
instructions before attempting to operate the machine.
When contacting Snorkel for service or parts information,
be sure to include the MODEL and SERIAL NUMBERS
from the equipment nameplate. Should the nameplate be
missing, the SERIAL NUMBER is also stamped on top
of the chassis at the front of the machine.
Component Identification
Right Side
Chassis
Lower
Controls
Upper Controls
Fuel Tank
Left Side
Platform
Main Boom
Tip Boom
Hydraulic Fluid Filter
Battery Disconnect
Switch
Platform
Foot Switch
Operator
Manual
Rear
Front
Front
Rear
Jib
Riser Boom
Riser
Power to Platform Inlet
Power to Platform Outlet
Engine Compartment
Engine • Hydraulic Pump • Battery
Level Sensor • Drive Valve Block
Tie-Down/Lifting Lugs
Pivoting Front Axle
Tie-Down/Lifting Lugs
Lanyard
Anchors
Tie-Down Lugs
Nameplate Location
Hydraulic Reservoir
