MICROPUMP, INC.
A Unit of IDEX Corporation
PO Box 8975, Vancouver, WA 98668-8975 • Phone: 360/253-2008 • Fax: 360/253-8294
MICROPUMP LIMITED
A Subsidiary of Micropump, Inc.
Forge Close, Eaton Socon, St. Neots, Cambridgeshire, PE 19 3TP England, • Phone: (44) (0) 1480-219844 • Fax: (44) (0) 1480-476959
REVISION
LTR. DESCRIPTION DATE BY
C REVISED PER ECN-3951 10/31/96 D.M.S.
PART NUMBER: 5479
Page 3 of 3
SPARE PARTS LIST
FOR GEAR PUMP MODEL 114/114-56C
PART NO.: 80943, 81427, 81744
ITEM
NO.
PART
NO.
DESCRIPTION UNITS PER
ASSEMBLY
1. 5698 SLEEVE (P/N 80943 ONLY) 1
2 5629 DRIVE HOUSING (P/N 80943 ONLY) 1
3 5705 HOUSING (P/N 81427, 81744 ONLY) 1
3 4799 CUP, MAGNET (P/N 80943 ONLY) 1
3 5947 CUP, MAGNET (P/N 81427, 81744 ONLY) 1
4 4709 * O-RING, VITON (P/N 81727 ONLY) 1
4 4820 * SEAL, TEFLON (P/N 81744, 80943 ONLY) 1
5 80405 MAGNET ASSEMBLY, DRIVEN 1
6 5010 SCREW (P/N 80943 ONLY) 2
6 4795 SCREW (P/N 81427, 81744 ONLY) 2
7 5021 PUMP BODY (P/N 80943 ONLY) 1
7 5880 PUMP BODY (P/N 81427, 81744 ONLY) 1
8 4833 * BUSHING 5
9 80562 * GEAR ASSEMBLY, DRIVING 1
10 80563 * GEAR ASSEMBLY, DRIVEN 1
11 5395 CAVITY PLATE 1
12 1508 DOWEL PIN 4
13 5007 BEARING PLATE (P/N 81427, 81744 ONLY) 1
13 5023 BEARING PLATE (P/N 80943 ONLY) 1
14 4989 * SEAL, TEFLON (P/N 81744, 80943 ONLY) 2
14 1634 * O-RING, VITON (P/N 81427 ONLY) 2
15 4720 SET SCREW 1
16 1437 SCREW (P/N 80943 ONLY) 6
17 5878 SCREW (P/N 81427, 81744 ONLY) 8
5794 BOLT (P/N 81427, 81744 ONLY) 4
81356 HUB ASSEMBLY (P/N 81427, 81744 ONLY) 1
5465 BUSHING INSERTION TOOL
80968 GEAR SERVICE KIT (P/N 80943, 81744 ONLY)
80567 GEAR SERVICE KIT (P/N 81427 ONLY)
* Parts available in Gear Service Kit only
Prices subject to change without notice.
