s POD Installation Instructions
1997 – 2002 Wrangler
3
Send wire harness and
terminal down through here.
Drill 1 in. diameter hole here on
passenger side under glove box area.
• Use supplied cable ties to tie down harness as required. Trim ends after all ties are cinched down snugly.
• Remove glove box and feed wire harness down behind glove box and out of the way for now.
• Now drill a 1” dia. hole where shown from inside of the Jeep below the glove box area.
• Install supplied grommet and feed connectors through the firewall into the engine compartment.
• Re-install the battery.
• Next remove the 4 counter sunk screws from the plastic to the bracket and slide the assembly off the
bracket before installing the Source mounting plate.
• Remove the two grounding terminal bolts using a 15mm socket located on firewall just above the
valve cover behind OEM harness and attach mounting plate. Be sure to reattach grounding
terminals! See below:
Grommet Pull carpet back
Do not over tighten
4 counter sunk screws!
15mm ground bolts
