s POD Installation Instructions
2012 - 2015 Jeep JK Wrangler
www.4x4s-POD.com
1
Remove these
Screws
Keep this hole clear!
It is used for the plastic
windshield header alignment stud
On some plastic pieces, you may have to
trim a small amount off in this area
on both sides to clear bracket.
Attach switch bezel assembly to the bracket using
the 10-32 Phillips head screws supplied. Do not
tighten until bezel fits snugly against plastic
windshield cover.
After installation
You must start engine to activate system!!!
Allow approximately 1 hour for installation
Tools required

Phillips head screw driver.

8mm, 10mm, 12mm sockets

T-20 TORX bit & T-25 TORX bit

Flashlight.

Remove the Freedom/Soft top for easier access during installation.

Remove existing plastic windshield header cover by swinging the visors out of the way and pulling the
plastic windshield header straight out until all 4 clips pop out of windshield frame.

Remove visor using the T-20 TORX bit.

Use a T-25 TORX to remove existing footmans loop from windshield frame.

Align the bezel bracket over the footman loop and reattach the assembly back on to the windshield frame
with the bezel bracket attached on the outside of the footman loop as shown below.

Re-install the plastic header back on and snap into place. Tuck the harness behind the plastic windshield.
