s POD Installation Instructions
1997 – 2002 Wrangler
2
Air Line
• Attach sun visor relocating brackets where shown to sun visor mounting bracket
using the 8-32 screws supplied.
• Attach the visor with relocating bracket using the existing T-40 TORX bolt and just snug it in place for now.
. !!! NOTE !!! Some aftermarket roll cages may
interfere with the sPOD visor relocating brackets,
so they may require slight modifications to them.
• Rotate sun visors around and push the plastic pin into sPOD bezel as shown below, then check alignment of
visor and then tighten the T-40 TORX screw. Check for alignment again and then adjust visor so it rotates
upward and clears sPOD bezel. If the visor hits the sPOD bezel, just slide the vinyl part of the visor over the
shaft and check for clearance again.
• Guide wire harness through sPOD header unit leaving plenty of wire behind the sPOD for future removal.
Keep the harness as close to the windshield rubber as possible. If you purchased the air gauge kit, then place
the air line under the rubber gasket and lead it all the way down the windshield and down through the dash.
Place stick back cable tie downs where shown as required for a clean look.
