s POD Installation Instructions
2012 - 2015 Jeep JK Wrangler
www.4x4s-POD.com
2
Look up into upper
left side of firewall
for the harness you
just passed through.
Use a screwdriver to make a
hole in foam to pass through
firewall.
Look on right side of brake
booster for pass through
Pull white connector through
Push white connector
through hole
Run white connector up
through opening in plastic
Plug connector in with
key facing outward
Use the flashlight

Guide wire harness through all the plastics going toward the driver’s side by lifting and tucking the
harness behind the plastic as you go. Feed the harness down behind the plastic vertical pillar and out the
side opening for now.

Next, remove the plastic cover on the driver’s side between the door and the side of the dash for access to
the firewall. Remove by just snapping it off.

Use this method and grommet on right side of brake booster for Standard Transmissions .

Use this method on lower right side of brake booster for Automatic Transmissions.
Wire harness
Sun visor / left side
Vertical “A” pillar
Use a small
screwdriver and
pry out plastic
cover.
Original rubber Plug
Form a hook on
the end of the fish
line and wrap the
white connector
with a little
electrical tape.
Fish Line
Do Not Use
This Hole!
Wire harness
Goes through
here
