Bunn Axiom Series - Manual (Page 19)

Page 19
FACTORY DEFAULTS
NO YES
SERVICE TOOLS ?
NO YES
BREW COUNTERS ?
NO YES
CALIBRATE FLOW ?
NO YES
SPRAY OZ/M: 25.0
(-) DONE (+)
PROGRAMMING FUNCTIONS - LEVEL 2 (cont.)
ADJUSTMENTS & OPTIONAL SETTINGS (CONT.)
View or enter the actual fl ow rate coming out of the sprayhead.
This is used to tell the internal controller how fast the water
is fl owing. Use the "CALIBRATE FLOW" screen to obtain the
most current fl ow rate.
Range: (3.0 to 75.0 oz) or (100 to 2200ml)
This function provides a 60 second test mode to capture water
from the sprayhead. This measurement will then give you the
numbers to enter into the "SPRAY OZ/M: xx" screen above.
NOTE: Should be performed after deliming and/or changing
sprayhead.
Tracks the total number of brew cycles completed. There is one
reset-able counter, and one life counter that is not reset-able
Allows the testing of individual components and the ability
