45
13.5 PC 650-2POWER
1) HD = High pressure 2) ND = Low pressure 3) 1MPa = 10 bar
Device type PC 650-2POWER Units Remarks
Item number 70-10-30
Dimensions l x w x h 537 x 451 x 577 mm
21.1 x 17.8 x 22.7 in.
Operating pressure max. 53 MPa
7700 psi
Delivery quantity High-
pressure 2 x 0.7 l/min simultaneously
2 x 0.18 gpm
Change-over
pressure 14 MPa from low to high
pressure
2000 psi
Delivery quantity Low
pressure 2 x 2.6 l/min simultaneously
2 x 0.69 gpm
Motor Power 2.2 (230/50) kW
(VAC/
Hz) single phase,
electric motor
Idle speed 2940 rpm
Volume of hydraulic
fl uid max. 27.5 / 23 l Fill/useful
volume,
horizontal
7.3 / 6.1 gal.
Ambient temperature -20 … +55 °C
-4 … 131 °F
Weight 76 kg including
hydraulic fl uid
168 lbs.
Specifi cation of
hydraulic fl uid HM 10 ISO 6743-4
