13
13 Technical data
Type LZR12/300EN LZR12/500EN LZR12/700EN LZR12/550PS LZR19/325
Ref. no. 84150/6101 84150/6102 84150/6103 84150/6088 84150/6092
Compressive force (kN)
(in all operating ranges)
120 190
Piston stroke (mm) 300 500 700 550 325
Length retracted (mm) 450 680 900 800 460
Length extended (mm) 750 1180 1600 1350 785
Dimensions wxh (mm) 171 x 82 192 x 82 100 x 200
Weight (incl. oil filling) (kg) 13.0 18.0 24.0 21.8 14.3
Operating pressure (MPa) 63*
Max permissible pressure see identification plate
Usable oil quantity (l) 1 0.5 0.8 1.2 0.7 0.8
DIN 14751
RZ1.1 2001 RZ1.2 2001 RZ1.3 2001
TP18 (TÜV) TP18 (TÜV) TP18 (TÜV)
European Norm HR 01-2000 HR 02-2000 HR 03-2000
prEN 13204 (April 98) (TÜV) (TÜV) (TÜV)
USA NFPA 1936
Technical Report No. 70000275-1
(TÜV-Produkt Service)
Type LTR6/570 LTR3,5/820EN LTR12/575EN LTR12/875EN
Ref. no. 84150/6089 84150/6106 84150/6056 84150/6055
Compressive force piston 1 (kN) 190 240
Compressive force piston 2 (kN) 60 120
Compressive force piston 3 (kN) 35
Stroke piston 1 (mm) 325 295 445
Stroke piston 2 (mm) 245 280 430
Stroke piston 3 (mm) 245
Piston stroke total (mm) 570 820 575 875
Length retracted (mm) 460 475 625
Length extended (mm) 1030 1295 1050 1500
Dimensions w x h (mm) 110 x 200 112 x 210
Weight (incl. oil filling) (kg) 16.9 17.7 16.7 20.9
Operating pressure (MPa) max. 63*
Max. permissible pressure see identification plate
Usable oil quantity (l) 1 1.0 1.5 1.4 2.2
DIN 14751
RZ10-93- RZ 03-01- RZ 01-01- RZ 02-01-
TP18 (TÜV) TP18 (TÜV) TP18 (TÜV) TP18 (TÜV)
European Norm HR 06-2001 HR 07-2001
prEN 13204 (April 98) (TÜV) (TÜV)
USA. NFPA 1936 Technical Report No. 70022561/5 (TÜV-Produkt Service)
* 1MPa = 10 bar;
1 Necessary oil quantity in the hydraulic power pack for operating the tool
(Difference in quantity piston / rod side)
