Road Armor 2003-2007 Chevy 2500,3500 Front Bumper User Manual

Page 3

• Place tape on the edges of the body to prevent the paint from scratching.

• Place the four 1/2” bolts welded to tabs in the bumper and push on the retainer washers

onto the bolts ( use a small socket to help pushe them on). Place bumper onto the brack-

ets making sure that all four bolt line up. Then use four washer, lock washers and nuts to

hold bumper in place.

• Picture: 9 A-B

• With the bumper in place adjust one side a a time till you get the it in the right location

then tight all the bolts. After bumper is tight trim inner fender to aline with bumper (be

careful on drivers side the windshield washer fuild bottle is right behing fender).

• Picture: 10

• Now replace front grill and plastic cover using the rivets that you took out
