Page 2
Suggested Lights Front Bumper:
Rigid Dually series
Vision X - Optimus Solo
Rear Bumper:
Rigid SR-M’s
License Plate Lights http://www.etrailer.com/Trailer-Lights/Optronics/LPL31CB.html
Verify you have all the hardware that was sent with the
Bumper. The front Bumper requires the following hard-
ware (all are Grade 8)
(14) Single Bolt Plates
(2) 1/2” Push On Retainers
(2) 1/2 - 13” X 5” Bolts
(18) 1/2” Flat Washers
(16) 1/2” Lock Washers
(16) 1/2” - 13 Hex Nuts
(1) Large logo kit
(2) Winch and Logo kit
(4) 1” Plastic plugs
On to prepping the vehicle for installation. Park on a level surface, remove the license plate, and disconnect the battery. Now mask
off the front and rear of the body to avoid scratches or chips in the paint when uninstalling/installing the bumpers.
Step 1 & 2 Remove bolts on the inner fender wells
Step 1
Step 2
