1044C-54 Series II 31200069 1-4
FRAME & ATTACHING PARTS
34 Ref REAR STABILIZER CYLINDER, (see Figure 9-8 for details)
35 Ref FRONT AXLE ASSY, (see Figure 5-2 for details)
36 Ref FRAME TILT CYLINDER, (see Figure 9-3 for details)
37 Ref REAR AXLE ASSY, (see Figure 5-10 for details)
38 4341020 1 TRANSMISSION MOUNT WELDMENT
39 0642018 4 HEX HD CAPSCREW, 5/8-11X2-1/4, GR5, (Before S/N 0160051140)
10700605 4 HEX HD CAPSCREW, 5/8-11X2-1/4, GR5, (S/N 0160051140 & After including
0160050734 & 0160050735)
40 4752000 8 PLAIN WASHER, 5/8, (Before S/N 0160051140)
10701408 6 PLAIN WASHER, 5/8, (S/N 0160051140 & After including 0160050734 &
0160050735)
41 4762000 6 LOCKWASHER, 5/8, (Before S/N 0160051140)
10701314 6 PLAIN WASHER, 5/8, (S/N 0160051140 & After including 0160050734 &
0160050735)
42 Ref TANK SUPPORT MOUNT, (see Figure 9-20 for details)
43 0100071 AR LOCTITE ® 262 TM , (apply to item 2 & 39), (S/N 0160009654 thru 0160040407
excluding 0160037824 & 0160038521)
0100011 AR LOCTITE ® 242 TM , (apply to item 2 & 39), (S/N 0160040413 & After including
0160037824 & 0160038521)
44 10700703 2 HEX HD CAPSCREW, 3/4-10X2-1/4, GR5
45 10701315 2 LOCKWASHER, 3/4
46 10717809 2 CLAMP
47 Ref VALVE PLATE, (see Figure 9-23 for details)
K1 10732579 1 CONVEX MIRROR SERVICE KIT, (includes item 32)
Figure 1-1 Main Frame Assembly (Continued)
Item Part Number Qty. Description Rev.
