MBW EXA30 User Manual
Page 14
- 11 -
ITEM
PART NO.
DESCRIPTION
QTY
1.
08025
RETAINING RING, INT N5000-500
2
2.
08226
FITTING, ELBOW
2
3.
08730
FITTING, ELBOW
2
4.
09750
HHCS, 3/4-16 X 11
4
5.
09935
NUT, STOP ELASTIC, THIN 1-1/2-12
2
6.
09936
WASHER
2
7.
12681
MOUNT, TORSION
4
8.
13451
WASHER, 5/8 STRUCTUAL
16
9.
13454
HHCS, 5/8-18 X 2-1/2
6
10.
13633
DRUM, 18” PADDED
2
11.
13638
BLADE, 18” EXA
1
12.
13644
BLADE, SCRAPER, 18”
1
13.
20446
VALVE, FLOW REG, EXA18
1
14.
13901
COVER, FRONT EXA
1
15.
13911
EXCITER, EXA18
1
16.
14817
FITTING,
2
17.
18845
HOSE, 1 x 18, SHORT ELBOW
2
18.
18812
STRIP, CLAMPING
4
19.
18817
MAT, RUBBER
2
20.
18837
SCRAPER TOOTH, WELDED, 2.0
4
21.
19290
BEARING, SPHERICAL PLAIN
2
22.
20807
HOSE, HYDRAULIC
1
23.
20809
GREASE FITTING, 1/8 NPT
2
24.
20810
AXLE, EXA18
1
25.
20811
HOSE, HYDRUALIC RETURN
1
26.
20812
WEAR SHIM
8
27.
20813
LOWER FRAME, EXA18
1
28.
20820
FRAME, UPPER EXA (PIN MOUNT)
1
20445
FRAME, UPPER EXA (FLAT TOP)
1
29.
F08LW
LOCKWASHER, 1/2
14
30.
F12LW
LOCKWASHER, 3/4
4
31.
F24LW
LOCKWASHER, 1-1/2
4
32.
F0518FN
NUT, FLANGE WHIZ-LOCK 5/16-18
2
33.
F1018ELN
LOCKNUT, 5/8-18 NYLOC
10
34.
F2406HN
NUT, HEX 1-1/2-6
4
35.
F051836HCS
HHCS, 5/16-18 X 4-1/2
2
36.
F061608FWS
FWLS, 3/8-16 X 1
12
37.
F081310HCS
HHCS, 1/2-13 X 1-1/4
6
38.
F081316
HHCS, 1/2-13 X 2
8
39.
F101818
HHCS, 5/8-18 X 2-1/4
4
40.
F240648HCS
HHCS, 1-1/2-6 X 6
4
