MBW R422 User Manual
Page 24
- 21 -
ITEM
PART NO.
DESCRIPTION
QTY
1.
01045
FILTER, FUEL, IN-LIN (FLOAT CARBURETOR ONLY)
1
20387
FUEL FILTER, INLIN (DIAPHRAM CARBURETOR)
2.
01052
CLAMP, HOSE
4
3.
01145
CLAMP, SPRING
1
4.
07351
TORSION MOUNT
2
5.
07916
FERRULE, THROTTLE LEVER
1
6.
20476
CAP, 2-1/4” (EPA)
1
7.
15183
HOSE, FUEL 1-1/2” LONG
2
8.
HOSE, FUEL, 3/16” I.D., (SEE ENGINE ASSEMBLY PAGE)
9.
20422
KIT, TANK, FUEL (INCLUDES ITEM #6)
1
10.
16414
VALVE, FUEL
1
11.
16586
GROMMET, 1/2”
1
12.
18510
BRACKET, HANDLE, RIGHT
1
13.
18511
BRACKET, HANDLE, LEFT
1
14.
18515
SNUBBER
2
15.
18742
THROTTLE, RATCHET STYLE
1
16.
19899
THROTTLE CABLE ASSEMBLY
1
17.
14946
CLAMP, TACH WIRE
1
18.
20713
BRACKET, LIFTING
1
19.
20719
HANDLE, COATED
1
20.
F032402FSS
FLAT HEAD SCREW, #10-24x1/4”
2
21.
F042004FWS
FLANGE SCREW, 1/4”-20 x 1/2” ZP
4
22.
F051807FWS
FLANGE SCREW, 5/16”-18 x 7/8” ZP
8
23.
F051808FWS
FLANGE SCREW, 5/16”-18 x 1” ZP
8
24.
F0518FN
NUT, FLANGE 5/16”-18 ZP
12
25.
20549
KIT, HANDLE ROLLER
1
AIR CLEANER COMPONENTS FOR “HA” MODELS ONY
26.
20544
ADAPTER TUBE, AIR CLEANER
1
27.
20714
AIR CLEANER
1
28.
20716
CLAMP, WORM DRIVE
2
29.
F051807FWS
FLANGE SCREW, 5/16”-18 x 7/8” ZP
2
30.
F0518FN
NUT, FLANGE 5/16”-18 ZP
2
20715
REPLACEMENT AIR FILTER (NOT SHOWN)
20718
EJECTOR BOOT, ALR CLEANER HOUSING (NOT SHOWN)
17602
KIT, TACHOMETER, NOT SHOWN.
20305
FUEL HOSE ASM. (Includes items:1, 2, 7 & 8)
20345
HC HANDLE REPLACEMENT KIT
