Koffee-King™ EXPLODED VIEW & PARTS LIST (continued)
19
ITEM
PART
NO.
DESCRIPTION
USED
ON
1
8700-16
Warmer Cover Plate, Black
All
8875-149
Warmer Cover Plate, Brown
All
4
8543-80
Clip, Panel Retaining
All
20
8543-23
Tinnerman Nut, #8 (not shown)
All
23
8543-69
Heyco
Bushing
All
33
8543-42
Spray Head Gasket
All
34
82727
Spray
Disk
All
34a
8543-45
Spray
Head
Retainer
All
35
8572-34
Door, Solenoid Access (Old-Style)
8540, 8541, 8572, 8573 & 8574
85089
Door, Solenoid (New-Style)
8540, 8541, 8572, 8573 & 8574
38
8574-10
Cover,
Electric
8574
40
8706-76
Button Plug 1-1/8"
All Canadian
41
18-50
Nut, Warmer Plate Retaining 1/4-28
All Canadian
47
8810-12
Button Plug (Non-faucet)
8541, 8542, 8543, 8571, & 8573
47a
8033-60
Button Plug (Hi-Limit)
8574
48
8033-55
Leveler, Adjustable Leg
All
8033-56
Cap,
Adjustable
Leg
All
81732
Adjustable
Leg
Assembly
All
70
8706-75
Button Plug (Timer)
8540, 8541, 8572, 8573 & 8574
101
8572-13
Top
Assembly
All
102
8512-56
Basin Cover Assy (w / Warmer)
8540, 8541, 8543
8542-6
Basin Cover Assy (no Warmer)
8542, 8571, 8572, 8573 & 8574
103
86666
Pour-Over
Assembly
All
108
8541-21
Basin Pan (Automatic)
8540, 8541, 8572, 8573 & 8574
8543-29
Basin
Pan
(Pour-Over)
8542,
8543,
8571
110
8542-110 Basin
Front
Label
8542
8543-160 Basin
Front
Label
8543
8541-160 Basin
Front
Label
8540
&
8541
8572-110
Basin Front Label
8572, 8573 & 8574
8571-20
Basin
Front
Label
8571
111
8542-25
Bottom Assembly (In-Line Pour-Over)
8542 & 8543
8540-25
Bottom Assembly (In-Line Automatic)
8540 & 8541
8571-13
Bottom Assy (3-Station Pour-Over)
8571
8572-33
Bottom Assy (3-Station Automatic)
8572 & 8573
Bottom
Assy
(3-Station Automatic)
8574
112
8541-155 Panel,
Front
8540
&
8541
8543-48
Panel.
Front
8542
&
8543
8571-3
Panel,
Front
8571
8572-10
Panel,
Front
8572,
8573
&
8574
114
8718-61
Panel, Bottom Plate (In-line)
8540, 8541, 8542 & 8543 (exc. ...CA)
8549-26
Panel, Bottom Plate (w/access hole)
8540CA, 8541CA, 8542CA & 8543CA
8752-66
Panel, Bottom Plate (3-Station)
8571, 8572, 8573 & 8574 (exc. ...CA)
8571-19
Panel, Bottom Plate (w/access hole)
8571CA, 8572CA, 8573CA & 8574CA
115
8572-16
Cover Warmer
8571, 8572, 8573, 8574
200
8942-6B
Brew
Chamber,
Black
All
8942-6
Brew
Chamber,
Brown
All
8707-6
Brew
Chamber,
Stainless
All
8766-11
Brew Chamber, Portion Pack, Black
All
8942-6PP
Brew Chamber, Portion Pack, Brown
All
201
POF
Filter Paper (case of 1000)
All
