Using iPod 23
Port Use
Dock connector port Connect the Dock to your computer or the power
adapter using the included USB 2.0 cable.
iPod connector Place iPod into the Dock to charge iPod, transfer
songs, view photos, and listen to music.
Line Out port Connect speakers using an audio cable with a
standard 3.5 millimeter stereo miniplug (see
page 24). Or connect the optional iPod AV Cable
to view photos on a television (see page 32).
S-video Out port Connect an S-video cable to view photos with
enhanced clarity on an S-video-equipped
television or video device (see page 32). You must
use an additional audio cable to hear sound with
a slideshow.
Dock connector port iPod connector
Line Out port S-video Out port
