4. Follow the directions that came with your
computer and replace the back panel or lid,
and reattach any cables you removed earlier.
Depending on the model you have, you will need to
slide the logic board back into place, remove the
communications port cover, replace a back panel,
replace a lid, and so forth.
5. Plug the AAUI connector from your network
transceiver cable into the AAUI port on your
card.
You need a specific AAUI-compatible transceiver for
the kind of media used for your network: thick coax,
twisted-pair, thin coax, or fiber-optic. The transceiver
connects your computer to the main network cable.
6. Turn on the computer’s power switch and
start up the computer.
You’ve made all the necessary hardware connections.
Next you’ll install and set up your network
communications software.
4
The AAUI
connector attaches
to the card’s port.
The cable also connects to the
appropriate AAUI-compatible
transceiver for your network.
