Apple AirPort Express v4.2 User Manual
Page 25
Using AirPort Express
25
Using AirPort Express With Your AirPort Extreme Network
The illustration below shows a wireless network with all of the above examples in a
single wireless network.
How to Set It Up
Â
Use the AirPort Setup Assistant to create a new network, join an existing AirPort
Extreme or AirPort Express network, and take advantage of all the AirPort Express
features.
DSL or cable
modem
to Line Out port
to USB port
to Internet
to Ethernet
port
Family Room
Living Room
AirPort Extreme
Base Station
