INSTALL
STEP 1: Installation of front fender
1)
2)
3)
4)
ELECTRA BICYCLE COMPANY , LLC. • 3270 CORPORATE VIEW, SUITE A, VISTA, CA 92081
TEL 760-607-2453 • ORDERLINE 800-261-1644 • FAX 760-598-7350 • ELECTRABIKE.COM
Place bicycle in stand (if available) and
remove front wheel.
Install fender stay to fender, using M4x9mm
machine screw and lock nut.
Remove front brake mounting bolt from
back of fork using 5mm hex wrench.
Thread brake caliper mounting bolt through
fender bracket.
Reattach brake and tighten mounting bolt.
Attach stay ends to fork dropout eyelets.
Reattach front wheel.
Close brake quick release, spin wheel and
make sure brake pads are not rubbing on
rim and that fenders are not rubbing on tire.
Check brake operation.
STEP 1:1
STEP 1:2
STEP 1:4 STEP 1:3
