PHCC Pro Series Pro Series 2400 Battery Backup Sump Pump System - Manual

IMPORTANT: Even if you have the Pro Series backup sump pump
system installed by someone else, you must read and follow the
safety information contained in this manual. Failure to do so
could result in property damage, serious injury, or death.
A/C-D/C
Battery Backup
Sump Pump System
Important Safety Warnings and
Instructions
Electrical precautions
1
Battery preparation 1
Battery precautions 1
Introduction
Items included in system
2
Additional items needed 2
Replacement parts list 2
System specifications 2
Pump & Pipe
Installation Instructions
Installation options
3
Direct discharge to outside 4
Connection to existing discharge 5
Direct discharge for narrow sumps 6
Connection to existing discharge
for narrow sumps
7
Battery Instructions 8,9
Control Unit Connections
Positioning the float switch
9
Connecting the pump 9
Installing the battery fluid sensor 10
Connecting the battery
10
Connecting two batteries 10
Connecting to AC power 10
Understanding the Warning
Lights and Alarms
Silencing the alarm
10
Battery fluid is low 11
Battery problem 11
Cleaning battery terminals 11
Replacing the battery 12
Power failure 13
Pump or fuse failure 13
Pump was activated 14
Replacing the pump 14
Battery power level 14
Testing the System
Testing the float switch
15
Connecting the Remote Alarm 15
Parts & Service Information
Technical support
15
Troubleshooting Guide 16
Warranty 17
Other Products 18
Instruction Manual & Safety Warnings
Table of Contents
