For Your Safe Flight Page 19
Scanner® Information Area
The Scanner® Information Area provides expanded information in the
form of alpha-numeric messages, parameters and calculations. In Auto-
Scan, parameters will ‘scan by’ once every 4 seconds (default). This rate
can be changed in Pilot Programming Mode. Tap the STEP button for
‘Manual’ selection of any parameter. Parameters for the installed options
will be displayed - uninstalled parameters will not appear.
DISPLAY PARAMETER DESCRIPTION
EGT 1436 CHT 382 EGT/CHT
Shows successive pairs of
EGT & CHT per STEP tap.
1580
TIT TIT 1 Turbine Inlet Temp #1
1490 TI2 TIT 2 Turbine Inlet Temp #2
204
OIL-T OIL TEMP Oil temperature
64 OIL-P OIL PRES Oil pressure
75 CLD SHOCK COOL CHT cooling rate (deg/min)
13.9
BAT BATTERY Battery/Bus voltage
23 OAT OAT Outside air temperature
40
DIF DIF Hottest minus coldest EGT
56 CRB CRB
Carburetor Air Temp (only
allowed if IAT not present)
145 CDT CDT
Compressor Discharge Temp
(only allowed if CRB not
present)
105 IAT IAT Intercooler Air Temp
-40
C-I CDT-IAT Intercooler cooling
RPM 2460 MAP 23.6 POWER RPM & MAP values
Calculated
68.0 REM
REM Calculated fuel remaining
12.7
REQ
FUEL
REQUIRED
Calculated fuel required to
reach waypoint (GPS interface
must be correct)
Calculated
55.2 RES
FUEL
RESERVE
Calculated fuel reserve at
waypoint (GPS interface must
be correct)
9.8
MPG
MILES PER
GALLON
Calculated fuel miles per units
(GPS interface must be
correct)
Calculated
04:32
H:M
ENDURANCE
Calculated time remaining to
fuel exhaustion
15.0 GPH
FUEL FLOW
RATE
Calculated fuel flow rate in
units per hour
7.2 USD FUEL USED Calculated fuel used
