Mueller, Inc. 24 x 24 Carport Instructions
9
HIGH EAVE RAKE LOW EAVE RAKE
½" x 1"
Flat Head Bolt
½" x 1"
Flat Head Bolt
#12 TEK
Screw (Color)
#12 TEK
Screw (Color)
½" x 1"
Flat Head Bolt
½" x 1"
Flat Head Bolt
#12 TEK
Screw (Color)
Stitch
Screws
Stitch
Screws
High Eave
Trim Rake
Trim
Rake
Trim
Low Eave
Trim
#12 TEK
Screw (Color)
#12 TEK
Screw (Color)
#12 TEK
Screw (Color)
Sheet Sheet
Trim Trim
C-Bar C-Bar
Cap
Channel
Cap
Channel
2" x 2"
Trim
2" x 2"
Trim
NOTE: Sheet is to
extend 6" on
low side.
