8
SPECIFICATIONS cont’d.
Output Characteristics
LIGHT OUT
Wavelength:
Model 106C: 1064nm ±30 nm
Model 155:1550 nm ±30 nm.
Model 130:1310 nm ±50 nm.
Spectral Width: 2 nm rms (from 50 uW to 1 mW).
Power Level:
1 mW max. (Peak or Baseline). 0 mW min.
Impulse is fixed at 50 µW Baseline and 0.5 mW Peak
(typical).
Power Level Resolution: 5 µW (from 50 µW to 1 mW),
Extinction Ratio: CW Mode and External Modulation Mode, has 5 µW
resolution from 0 to 1 mW
Mesial Level: ∞ (zero Baseline), or 20.0 to 1.01.
Pulse Adjustment Range: 25 µW (zero Baseline), or 55 µW to 0.995 mW.
(Max. pulse size: min. pulse size.) 20 dB (non-zero
Baseline), 13 dB (zero Baseline), 20 dB (CW.
External
Modulation).
Accuracy, Absolute: ±1 dB (from 50 µW to 1 mW).
Accuracy, Relative: ±0.5 dB (±10 %) from 100 µW to 1 mW (Pulse
Mode).
±0.05 dB (±0.5 %) from 50 µW to 1 mW (CW.
External
Modulation).
Temperature Coefficient: 0.05 dB/°C.
Transition Times (10 to 90%): 0.5 ns rise time, 1 ns fall time (zero Baseline),
1 ns rise time, 1 ns fall time (nonzero Baseline).
Insertion Delay: 35 ns, typical (between mainframe TRIG OUT and
LIGHT OUT; see Figure 1-1).
Jitter: 100 ps rms (between mainframe TRIG OUT and
LIGHTOUT).
Connector: ST, 8/125 um single-mode fiber, 0.12 NA (contact
factory for other connectors).
