PARTS LIST AND SCHEMATICS
R9
213-301 300 OHMS 5% 1/4 W COMP R54 NOT USED
R10 213-332 33 K 5% 1/4 W COMP R55 NOT USED
R11 244-035 2 K MULTITURN R56 222-026 110 K 1/% 1/4 W MF
R12 NOT USED R57 222-026 110 K 1/% 1/4 W MF
R13 NOT USED R58 244-011 1 K MULTITURN
R14
NOT USED R59 NOT USED
R15 NOT USED R60 NOT USED
R16 NOT USED R61 NOT USED
R17 222-022 4.99 K 1% 1/4 W MF R62 NOT USED
R18 222-045 4.22 K 1% 1/4 W MF R63 NOT USED
R64 NOT USED
R19 244-035 2 K MULTITURN
R20 213-103 10 K 5% 1/4 COMP R65 222-026 110 K 1/% 1/4 W MF
R21 213-473 47 K 5% 1/4 COMP R66 222-026 110 K 1/% 1/4 W MF
R22 244-036 10 K MULTITURN R67 213-102 1 K 5% 1/4 W COMP
R23 NOT USED R68 213-102 1 K 5% 1/4 W COMP
R69 222-026 110 K 1/% 1/4 W MF
R24 213-104 100 K 5% 1/4 W COMP
R25 213-105 1 M 5% 1/4 W COMP R70 222-055 102 K 1% 1/4 W MF
R26 213-102 1 K 5% 1/4 W COMP R71 222-070 95.3 K 1% 1/4 W MF
R27 213-102 1 K 5% 1/4 W COMP R72 222-026 110 K 1/% 1/4 W MF
R28 213-104 100 K 5% 1/4 W COMP R73 222-025 110 K 1/% 1/4 W MF
R74 222-026 110 K 1/% 1/4 W MF
R29 213-274 270 K 5% 1/4 W COMP
R30 213-131 130 OHM 5% 1/4 W COMP R75 214-080 65 OHM 5% 1/8 W COMP
R31 222-071 1 M 1% 1/4 W MF R76 222-051 10K 1% 1/4 W MF
R32 222-071 1 M 1% 1/4 W MF R77 222-043 237 K 1% 1/4 W MF
R33 213-102 1 K 5% 1/4 W COMP R78 222-051 10 K 1% 1/4 W MF
R79 213-150 15 OHM 5% 1/4 W COMP
R34 213-105 1 M 5% 1/4 W COMP
R35 213-105 1 M 5% 1/4 W COMP R80 222-017 215 K 1% 1/4 W MF
R36 213-104 100 K 5% 1/4 W COMP R81 213-820 82 OHM 5% 1/4 W COMP
R37 244-036 10 K MULITURN R82 213-330 33 OHM 5% 1/4 W COMP
R38 213-820 82 OHM 5% 1/4 W COMP R83 244-032 50 OHM 20-TURN
R84 213-101 100 OHM 5% 1/4 W COMP
R39 222-071 1 M 1% 1/4 W MF
R40 222-071 1 M 1% 1/4 W MF R85 222-026 110 K 1/% 1/4 W MF
R41 213-513 51 K 5% 1/4 W COMP R86 213-102 1 K 5% 1/4 W COMP
R42 244-036 10 K MULTITURN R87 213-301 300 OHM 5% 1/4 W COMP
R43 213-512 5.1 K 5% 1/4 W COMP R88 213-102 1 K 5% 1/4 W COMP
R89 214-501 500 OHM 5% 1/8 W COMP
R44 213-201 200 OHM 5% 1/4 W COMP
R45 213-391 390 OHM 5% 1/4 W COMP R90 214-580 68 OHM 5% 1/8 W COMP
R46 213-512 501 K 5% 1/4 W COMP R91 214-510 51 OHM 5% 1/8W COMP
R47 213-102 1 K 5% 1/4 W COMP R92 214-131 130 OHM 5% 1/8 W COMP
R48 213-472 4.7 K 5% 1/4 W COMP R93 214-391 390 OHM 5% 1/8 W COMP
R94 214-510 51 OHM 5% 1/8 W COMP
R49 NOT USED
R50 222-014 499 OHM 1% 1/4 W MF R95 222-026 110 K 1/% 1/4 W MF
R51 222-014 499 OHM 1% 1/4 W MF R96 213-106 10 M 5% 1/4 W COMP
R52 213-471 470 OHM 5% 1/4 W COMP R97 213-102 1 K 5% 1/4 W COMP
R53 NOT USED R98 214-510 51 OHM 5% 1/8 W COMP
R99 213-102 1 K 5% 1/4 W COMP
R100 213-103 10 K 5% 1/4 W COMP
