X-PLORER PAC ASSEMBLY INSTRUCTIONS
Includes:
# Description Description Descripcion
1 Tent body Corpes de tente Cuerpo de tienda
1
Fly sheet / vestibule Feuille de renseignements /
vestibule Toldo impermeable / vestíbulo
2
Shock-corded tent poles Montants de tents de choc-
corded Postes de tienda de choque-
corded
1 Carrying bag Sac de stoackage Bolso de almacenaje
1 Pole bag Sack de Poteau (pole) Bolso de poste
1 Stake bag Sac d’intérêt (de pieu) Bolso de interés (estaca)
16 Stakes Intérêt (pieux) Intereses
4 Guide rope Guide Corde Guía de la cuerda
1 Sleeping bag Sac de couchage Saco de dormir
1 Stool Chaise Silla
SELECT A CAMPSITE: For greater camping enjoyment and comfort search for a fairly level and
soft spot that is protected from the wind and elements. Clear away any debris such as sharp
stones and sticks, which might abrade or puncture the tent floor make sure the area will also
drain well when it rains.
1. UNROLL THE TENT
Remove the tent from the carrying bag and unroll the tent. Lay the floor flat on the ground
with the door partially unzipped and facing the desired direction.
2. ASSEMBLE THE POLES
Remove the poles from the bag. Assemble the poles. Make certain that each pole is fully
inserted into the next pole section.
3. PITCHING THE TENT
Push the shortest pole through the pole sleeve at the rear of the tent. Place each pole into
the pole sleeve and into the pin at the corner of the tent. Attach the pole clips to the poles.
Repeat the above with the longer pole, pushing it through the pole sleeve at the front of the
tent.
Stake down the tent by using the stakes and the rings on the corners of the tent.
4. ASSEMBLE THE RAIN FLY
Drape the fly over the tent positioning the large gray panel, with zipper, over the front door.
Adjust the straps for the top section of the Pin & Ring to their longest settings and attach to
the Fly bottoms. Reach under the flysheet and wrap the Velcro straps located underneath
around the corresponding tent poles. Stake out the rear of the fly, taking care not to pull the
fly too tight.
Option 1: Stake out the front vestibule by staking two of the four base loops located on each
side of the fly zippers. Roll back the center of the vestibule door by unzipping both zippers
and securing the door with the toggles and fabric loops.
Option 2: Roll back the two side panels and leave the center section staked down.
