OVERVIEW
OVERVIEW
6
Direct-Access
Port Selectors
Port Status
Indicator LEDs
Console PS/2
Mouse/Keyboard
Ports
Console VGA Port
1st Computer
PS/2 Mouse/Keyboard
Ports
2nd Computer
PS/2 Mouse/Keyboard
Ports
2nd Computer
VGA Port–VGA 2
2nd Computer
USB Port–USB 2
2nd Computer
Audio/Microphone Jacks
1st Computer
USB Port–USB 1
Removable Shroud
Base
Front View
Fig. 1
Back View
Fig. 2
1st Computer
Audio/Microphone Jacks
1st Computer
VGA Port–VGA 1
Console
Audio/
Microphone
Jacks
DC Power Jack
Unit Display Diagrams
SOHO Series 2-Port KVM Switch with Audio, PS/2 and USB shown
