1.2
PARTS IDENTIFICATION
Portable Forced
Air Heaters
Model
Item Description CP100C
1 Regulator, Single Stage 130-21856
2 Hose, 3/8 in. ID x 10 ft. 400-21841
3 Adapter, Hose 310-06654
4 Cord, Power 120-09139
5 Panel, Left with Marking 500-21795
6 Case, Back 271-21794
7 Panel, Right 271-21796
8 Case, Front 271-21798
9 Control, Ignition 120-21813
10 Relay with Clips and Screws 400-21816
11 Tube, Manifold with Nuts and Sleeves 550-21805
12 Union 130-21809
13 Valve, Heat Adjustment 130-21806
14 Ell, 1/4 in. 130-01425
15 Valve, Safety Control with Screen 550-21808
16 Screen 130-20391
17 Elbow 130-21807
18 Case, Barrel Bottom 271-21794
19 Switch, Backflash 400-21855
20 Bolt 130-03140
21 Nut 130-04955
22 Mount, Motor 220-21828
23 Motor 120-21830
24 Fan 130-21829
25 Thermocouple with Retaining Sleeve 550-21811
25A Sleeve, Thermocouple Retaining (Not Illustrated) 130-21812
26 Igniter 130-21803
27 Ring, Bowed 130-08460
28 Ring, Flat 130-05847
29 Orifice with Rings 550-21802
30 Chamber, Heat with Igniter, Orifice and Burner Plate 500-21799
31 Guard, Inlet 225-21792
32 Case, Top 271-21793
33 Handle with Screws 550-03941
WIRE S SELECTION TTABLE
DESCRIPTION COLOR LENGTH ((IN.) PART N NO.
Ignition Control terminal “N” to
L1 wire nut White 5 1/2 120-21819
Ignition Control terminal “L” to
L2 wire nut Black 5 1/2 120-21820
Relay terminal #7 to L1 wire nut White 4 3/4 120-21821
Relay terminal #8 to L2 wire nut Black 4 3/4 120-21822
Ignition Control terminal #2 to
ground screw Green 8 120-21823
Backflash Switch to Thermocouple
energy cut-off block terminal Yellow 16 120-21824
Relay terminal #5 to Thermocouple
energy cut-off block terminal Yellow 12 120-21825
Relay terminal #3 to Backflash
Switch Yellow 12 120-21825
Ignition Control terminal #1 to
Igniter terminal Red 13 120-21826
FASTENER S SELECTION TTABLE
DESCRIPTION APPLICATION PART N NO.
Screw Case 130-07288
