ARB 4420110 - Manual (Page 2)

Last Rev Date: 05/05/2009 Page 2 of 3 Fitting instructions# 3783245
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
5mm hex key
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT :
Protective eyewear Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.
WHERE USED PART No QTY DESCRIPTION
3193763 2 FJ Cruiser Rocker rail skid plates
6151301 24 Cage nut M8 x 1.25
6151307 24 Screw M8 x 20mm button head socket
4581045 24 Washer flat M8 black
SKID PLATE TO ROCKER
RAILS
4581047 24 Washer Spring M8 black
