11-01-06 Page 1 of 4 3783019
ARB TOYOTA HJ100 2002 IFS, SIDE STEP AND FRONT RAIL
PRODUCT No. FRONT RAIL 4413250 or 4413270
SIDE STEP 4413260
FITTING KIT 6171750
USE QTY DESCRIPTION
SIDE STEP TO CHASSIS 2 BOLT ‘U’ M12 x 1.75 x 175mm x 100mm
REAR 4 ½” SPRING WASHERS
4 ½” FLAT WASHERS
4 M12 NUTS
1 FOAM TAPE
4 SMALL SPACER
SIDE STEP TO CHASSIS 2 BOLT ‘U’ M12 x 1.75 x 175mm x 100mm
MIDDLE 4 ½” FLAT WASHERS
4 ½” SPRING WASHERS
4 M12 NUTS
2 SPACER
SIDE STEP TO CHASSIS 2 BOLT ‘U’ M12 x 1.75 x 175mm x 100mm
FRONT 4 ½” FLAT WASHERS
4 ½” SPRING WASHERS
4 M12 NUTS
2 SPACER
RAIL TO STEP LOCKING BOLT 4 M8 BOLT x 20mm
4 M8 FLAT WASHER
4 M8 FLANGE NUT
SIDE RAIL TO BULLBAR 4 SIDE RAIL CLAMP
6 M8 BOLT X 70mm DOME HEAD BLKZP
6 M8 NYLOC NUT BLACK
6 M8 FLAT WASHER X 17mm OD BLACK
4 SIDE/RAIL RUBBER PLUG
CHECKER TOP TO STEP 1 CHECKER TOP PLATE LHS
1 CHECKER TOP PLATE RHS
14 M6 BOLT x 25 mm DOME HEAD
14 M6 FLANGE NUT
14 M6 FLAT WASHER
2 ARB DECAL
Tools Required
Basic Metric Spanner and Socket set, “G” Clamp, 3.0mm, 8.5mm and 10mm drill bit, electric
drill, Stanley knife and a tube of neutral cure Silicon.
