Page 38: Itemized parts list
7 Parts List
36
7.2
Itemized Parts List
(See exploded diagram figure 25.)
AIR LOCKER MODEL No. :
RD87
ITEM # QTY
DESCRIPTION
PART #
01
1
FLANGE CAP
023702
02
1
CLUTCH GEAR
050701
03
1
DIFFERENTIAL CASE
012804
04
4
PISTON SPRING
150107
05
3
CROSS SHAFT RETAINING PIN
120403
06
1
LONG CROSS SHAFT
060106
07
2
SHORT CROSS SHAFT
060306
08
1
PISTON
040801
09
1
U-RING
160306
10
1
CYLINDER CAP ASSEMBLY
031303
11
8
CYLINDER CAP RETAINING BOLT
200211
12
8
TAB WASHER – 6mm
150402
13
1
TAPERED ROLLER BEARING
NOT SUPPLIED
14
1
CLAMPING PLATE
090401
15
1
SPLINED SIDE GEAR
131202
16
4
PINION THRUST WASHER
151108
17
4
PINION GEAR
140601
18
1
SPIDER BLOCK
070701
19
1
SIDE GEAR
131102
20
2
SIDE GEAR THRUST WASHER
151008
21
1
ADJUSTER NUT
100601
22
1
SEAL HOUSING
081401
23
2
SEAL HOUSING O-RING
160208
24
3
SEAL HOUSING SCREW
200502
*
1
RING GEAR SPACER
190103
*
1
BULKHEAD KIT, O-RING TYPE, 3.5-5mm
170105
*
1
5mm PUSH-IN FITTING (RI 5 1/8”)
170201
*
1
NIPPLE, 1/8” BSP, MALE TO MALE
170501
*
1
NYLON AIR LINE (5mm Dia X 6m long)
170301
*
1
SOLENOID VALVE
180103
*
1
ON/OFF SWITCH
180209
*
1
SWITCH COVER ‘FRONT’
180210
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
210287
* Not illustrated in exploded view.
