2 Removing the Existing Differential
5
2.1
Vehicle Support
c Safely secure the vehicle on a hoist. We recommend supporting
the vehicle on a chassis hoist to keep the differential area at a
convenient working height and to leave the wheels and axles free
to be rotated and removed.
c Once supported off the ground, release the parking brake and
leave the vehicle in neutral. Chock the wheels if necessary.
2.2
Differential Fluid Drain
c Position a fluid drain reservoir under the differential.
c Remove fluid drain plug to empty all differential oil.
HINT : This is a good time to check for metal particles in
your oil which may indicate a worn bearing or
differential component.
2.3
Removing the Axles and Differential
c Disconnect the CV joints from the axle flanges.
c Disconnect the drive shaft from the flange of the differential.
c Remove the differential from the vehicle. (Refer to your vehicle’s
service manual)
NOTE : The differential housing is heavy and quite difficult to
handle when covered in oil. Do not drop it!
