3 Installing the Air Locker

11

3.2

Installing the Carrier Bearings

NOTE :

The Air Locker has been designed to employ higher
rated 50mm carrier bearings, instead of the 45mm
carrier bearings used on the OE Nissan diff center.
Due to this it is not possible to re-use the original
bearings, and 50mm bearings must be purchased:

Timken # 32010X-32010X

ARB # 160116

Apply a thin film of high pressure grease to the bearing journals of

the Air Locker, then press the bearing cones onto the bearing
journals as shown in Figure 5.


Figure 5.
