4 Installing the Air Locker
23
4.8 Final Air Locker Assembly
c Remove the seal housing, shim pack, and master shim, and clean
all parts of the differential assembly. It is very important to make
sure the seal housing grooves are free from any contaminants
(e.g., water, dirt, metal fillings, etc.)
c Lubricate the O-rings with oil (prior to assembly), then stretch them
over the bearing journal and release them into the grooves.
NOTE : Do not roll the O-rings onto the seal housing as this
will damage them.
c Place the bearing cups onto their respective bearing cones.
c Install the seal housing over the O-rings by gently applying a
downward twisting motion. This will allow the O-rings to gently
engage.
c Ensure that the thrust block has been inserted into the Air Locker if
required (section 2.7).
c Assemble the shim pack and master shim.
c Point the seal housing tube straight out of the housing, hold the
shims and tapered roller bearing cups in place, and insert and hold
the Air Locker into the differential housing.
c Install the bearing cap on the ring gear side.
c Check to see if the bearing cap on the seal housing side fits over
the tube without fouling.
NOTE : Do not forget to check the bearing caps are turned the
correct way around.
c Install all bearing cap bolts and torque to manufacturer’s specs.
4.9
Final Backlash Checking
c Relieve all tension on the housing spreader.
c Tighten all bearing cap bolts with a torque wrench to the torque
specified in your vehicle manufacturer’s service manual.
c Set a depth indicator on one of the ring gear teeth as in
Figure 15.
