Page 46: Itemized parts list
7 Parts List
44
7.2
Itemized Parts List
(See exploded diagram figure 31.)
AIR LOCKER MODEL No. :
RD102
ITEM # QTY
DESCRIPTION
PART #
01
1
SPLINED SIDE GEAR
131601H
02
1
SPIDER BLOCK
070801
03
1
LONG CROSS SHAFT
061302
04
1
SIDE GEAR
131501H
05
2
SIDE GEAR THRUST WASHER
151011
06
2
COUNTERSUNK SCREW
200213
07
2
CROSS SHAFT RETAINING PIN
120601
08
2
SEAL HOUSING O-RING
160235
09
1
SEAL HOUSING ASSEMBLY
081801
10
2
SHIM KIT
SHK003
11
2
TAPERED ROLLER BEARING
160109
12
1
FLANGE CAP ASSEMBLY
028504
13
1
BONDED SEAL
160701
14
1
CLUTCH GEAR
050803
15
8
RETURN SPRING
150107
16
1
SHORT CROSS SHAFT
061402
17
3
PINION GEAR
140801H
18
3
PINION THRUST WASHER
151112
19
1
DIFFERENTIAL CASE
013104
*
1
BULKHEAD KIT,O-RING TYPE,3.5-5mm
170105
*
1
PUSH-IN FITTING,5mm (R1 5 1/8”)
170201
*
1
AIR LINE (5mm DIA X 6m LONG)
170301
*
1
NIPPLE, 1/8” BSP,MALE TO MALE
170501
*
1
SOLENOID VALVE
180103
*
1
ACTUATOR SWITCH
180209
*
1
SWITCH COVER (REAR)
180211
*
10
CABLE TIE
180301
*
1
WARNING LABEL
210101
*
1
BUMPER STICKER
210102
*
1
OPERATION & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102102
* Not illustrated in exploded view.
