544D 91364001 12-114
OPTIONS
Figure 12-30 Adjustable Tilt on Joystick
Item Part Number Qty. Description Rev.
91365021 1 ADJUSTABLE TILT ON JOYSTICK, (if equipped), (includes all items) C
1 91033483 1 HYD VALVE POSITION KIT
2 91163236 1 COMBINATION VALVE
3 84719163 1 HOSE ASSY
4 84719167 1 HOSE ASSY
5 2220473 1 ELBOW, 90 DEGREE, (includes item 21)
6 2220501 2 ELBOW, 45 DEGREE, (includes item 21)
7 88201015 2 HEX HD CAP SCREW, 1/4-20X3-1/2, GR5
8 88551009 2 LOCKWASHER, 1/4
9 2220371 3 CONNECTOR, (includes item 21)
10 91301020 1 SPACER
11 2220635 1 SWIVEL NUT RUN TEE, 3/8 TUBE
12 84719166 1 HOSE ASSY
13 2220606 1 RUN TEE, (includes item 21)
14 91303041 1 BOOM CONTROL DECAL
15 4460476 1 WEATHER PACK CONNECTOR, (shroud)
16 4460475 3 WEATHER PACK CONNECTOR, (male pin)
17 91143187 3 WEATHER PACK CONNECTOR, (cable seal)
18 90207719 2 JUMPER WIRE-GREEN
19 84717295 1 HOSE ASSY
20 91083490 1 JOYSTICK HARNESS
21 88591204 7 O-RING
22 91361019 1 MOUNTING PLATE
23 88201019 2 HEX HD CAPSCREW, 5/16-18X7/8, GR5
24 88551010 2 LOCKWASHER, 5/16
25 88561003 2 FLAT WASHER, 5/16
26 91163242 1 PANEL MOUNT FLEXIBLE SHAFT
27 91363055 1 CONTROL KNOB
28 91363056 1 CONTROL DECAL
