FRAME & ATTACHING PARTS
544D 91364001 1-8
36 91033485 1 SEAT WITH ARMREST, (std.), (Before S/N 0160016097 excluding
0160015710, 0160015711 & 0160015915) C
91563158 1 SUSPENSION SEAT WITH 2 IN SEAT BELT,
(S/N 0160016097 & After including 0160015710, 0160015711 & 0160015915) E
1001101085 1 SUSPENSION SEAT WITH 2 IN SEAT BELT, (includes items 81 thru 87)
7026904 1 ARMREST KIT
91124107 1 SLIDE ADJ. KIT, (use with std. seat), (Before S/N 0160016097 excluding
0160015710, 0160015711 & 0160015915)
91043237 1 GRAMMER SEAT, (opt.), (Before S/N 0160016097 excluding 0160015710,
0160015711 & 0160015915)
88201020 4 HEX HD CAPSCREW, 5/16-18X1, GR5, (use with opt. seat), (Before
S/N 0160016097 excluding 0160015710, 0160015711 & 0160015915)
37 77143006 8 WHIZ-LOCKNUT, 5/16-18
38 91081475 1 HEATER COVER PLATE, (S/N 0160000976 thru 0160012366 excluding
0160012298)
Ref HEATER COVER PLATE, (S/N 0160012437 & After including 0160012298),
(see Figure 6-1 for details)
39 91141329 1 VALVE ACCESS COVER, (S/N 0160000976 thru 0160012366 excluding
0160012298)
Ref VALVE ACCESS COVER, (S/N 0160012437 & After including 0160012298),
(see Figure 6-1 for details)
40 91361005 1 BELLY PAN, (S/N 0160000976 thru 0160012366 excluding 0160012298)
Ref BELLY PAN, (S/N 0160012437 & After including 0160012298),
(see Figure 6-1 for details)
41 91083533 10 FENDER WASHER, 1-1/2, OD
42 91403230 1 MANUAL CASE
43 77143013 4 WHIZ-LOCKNUT, 1/4-20
44 77143006 2 WHIZ-LOCKNUT, 5/16-18, (use with item 58), (not shown)
45 1 TILT GAUGE, (S/N 0160000976 thru 0160005687), (no longer available, use
8466306 for service)
8466306 1 TILT GAUGE, (with adhesive), (S/N 016005766 & After)
46 88204912 1 HEX HD CAPSCREW, 1/4-20X1, (S/N 0160000976 thru 0160005687)
47 88561107 1 FLAT WASHER, (S/N 0160000976 thru 0160005687)
48 88521204 1 LOCKNUT, 1/4-20, (S/N 0160000976 thru 0160005687)
49 Ref OPEN CAB, (see Figure 6-1 for details)
50 91361007 1 DECK COVER
51 91143357 1 HORN ASSY
54 77133177 1 HEX HD CAPSCREW, 5/16-18X1-3/8, GR5
55 77133139 1 CLAMP SET
56 77133140 1 COVER PLATE
57 91363018 8 WHIZ-LOCK SCREW, 5/16-18X1
58 91363065 1 HOSE GUARD, (not shown), (located under dash panel, beneath steering
column)
59 4892500 4 HARDENED WASHER, 7/8
60 86683122 1 TIE WRAP
64 88261020 4 SOCKET BUTTON HD CAPSCREW, 5/16-18X1/2
65 91143348 2 CLAMP BAR
66 91551034 1 AIR DAM SUPPORT
67 91551033 1 AIR DAM SUPPORT
68 83201158 4 HEX HD CAPSCREW, 7/8-9X1-3/4, (torque to 450-475 lb-ft)
Figure 1-1 Frame Shrouding & Trim (Continued)
Item Part Number Qty. Description Rev.
S/N 0160000976 thru 0160034720
including 0160035922
