SIZE: DRAWN BY:
TITLE: WIZARD SYSTEM WITH
MOTION & PRESENCE
SEPARATED
A
NOTES: BROWN WIRE MUST BE CONNECTED TO GROUND OR COMMON
100 ENTERPRISE DRIVE
PITTSBURGH, PA 15275
PHONE: (412) 249-4100
FAX: (412) 249-4101
EMAIL: www.beasensors.com
REV BY:
KJG JEG
80.0003.02
SCALE: DATE:
NONE 17 APR 2005
PART NO:
SHEET
1 OF 1
EXTERIOR WIZARD
DOOR CONTROL
COM -
INTERIOR
ACTIVATION
SAFETY (BEAM)
INPUT
EXTERIOR
ACTIVATION
24 V
TRANSFORMER
INTERIOR WIZARD
ACT
COM -
ACT
COM -
ACT
IF AFTER TROUBLESHOOTING A PROBLEM, A SATISFACTORY SOLUTION CANNOT BE ACHIEVED, PLEASE CALL B.E.A., INC.
FOR FURTHER ASSISTANCE DURING EASTERN STANDARD TIME AT 1-800-523-2462 FROM 8AM - 5PM. FOR AFTER-HOURS,
CALL EAST COAST: 1-866-836-1863 OR 1-800-407-4545 / MID-WEST: 1-888-308-8843 / WEST COAST: 1-888-419-2564. DO NOT
LEAVE ANY PROBLEM UNRESOLVED. IF YOU MUST WAIT FOR THE FOLLOWING WORKDAY TO CALL B.E.A., LEAVE THE
DOOR INOPERABLE UNTIL SATISFACTORY REPAIRS CAN BE MADE. NEVER SACRIFICE THE SAFE OPERATION OF THE
AUTOMATIC DOOR OR GATE FOR AN INCOMPLETE SOLUTION.WEB: WWW.BEASENSORS.COM
