Philips AZ100717 - Manual (Page 4)

5
AZ 1007/14
page
5
English
POWER SUPPLY GENERAL OPERATION RADIO
AC MAINS
1. Check if the mains voltage as shown on the type plate on the
base of the set, corresponds to your local mains voltage. If it
does not, consult your dealer or service organisation.
2. If your set is equipped with a voltage selector, adjust it so
that it matches with the local mains.
3. Connect the mains lead to the MAINS socket and the wall
socket.
™ The mains supply is now connected and ready for use.
4. To switch off completely, withdraw the mains lead from the
wall socket.
• Disconnect the mains lead from the wall socket to protect
your set during heavy thunderstorms.
GENERAL OPERATION
1. To switch on the set, adjust the source selector.
2. Adjust the sound using the VOLUME and DBB controls.
3 To switch off the radio, adjust the source selector to the
TAPE/
POWER OFF
position, with the cassette keys released.
RADIO RECEPTION
1 Set the source selector to RADIO.
2 Adjust the sound using the VOLUME and DBB controls.
3. Select the wave band FM/MW using BAND.
4. Tune to a radio station using TUNING.
5. To switch off, set the source selector to the TAPE/
POWER OFF
position (with the cassette keys released).
To improve radio reception
• For FM, pull out the telescopic aerial.
Incline and turn the aerial. Reduce its length if the signal is
too strong (very close to a transmitter).
• For MW (AM), the set is provided with a built-in aerial so
the telescopic aerial is not needed. Direct the aerial by
turning the whole set.
SEARCH
STOP-OPEN PAUSE
DYNAMIC BASS BOOST
POWER POWER
VOLUME VOLUME
DBB DBB DYNAMIC DYNAMIC BASS BOOS T BASS BOOST
DYNAMIC BASS BOOST
BAND
FM AM
TUNNING
MHz kHz 530
800
1000 1300 1700
92
88
96 100
104 108
• FM • AM
POWER
VOLUME
DBB DYNAMIC BASS BOOST
SEARCH
STOP-OPEN PAUSE
DYNAMIC BASS BOOST
POWER POWER
VOLUME VOLUME
DBB DBB DYNAMIC DYNAMIC BASS BOOS T BASS BOOST
